Illumination Engineering

Illuminance E is luminous flux per unit area (lux = lm/m²). For a point source, the inverse-square law gives E = I/r² on a surface facing the source, and the cosine law adds a cosθ factor when the surface is tilted.

Room lighting uses the lumen method: total flux required = E × area / (UF × MF), where the utilisation factor accounts for flux reaching the working plane and the maintenance factor for dirt and lamp ageing.

(lux = lm/m²)

(candela × solid angle)

Relation 1 —

(lux = lm/m²)

Write this relation with symbols exactly as in Art & Science of Utilisation of Electrical Energy — H. Partab before substituting numbers. Examiners award partial marks for a correct setup even when arithmetic slips.

Relation 2 —

(candela × solid angle)

Write this relation with symbols exactly as in Art & Science of Utilisation of Electrical Energy — H. Partab before substituting numbers. Examiners award partial marks for a correct setup even when arithmetic slips.

Relation 3 —

Write this relation with symbols exactly as in Art & Science of Utilisation of Electrical Energy — H. Partab before substituting numbers. Examiners award partial marks for a correct setup even when arithmetic slips.

The number of luminaires = required total flux / (flux per luminaire). The utilisation factor depends on room geometry (room index) and surface reflectances; the maintenance (depreciation) factor is typically 0.7–0.8.

For a lamp above a point, the illuminance directly below is E = I/h²; at a point offset so the ray makes angle θ, E = (I cosθ)/d² = (I cos³θ)/h² on the horizontal plane.

Good design also considers glare, uniformity and colour rendering, not just average lux.

State assumptions explicitly before using any relation for illumination engineering — steady state, uniform properties, linear elastic material, ideal gas, incompressible flow, etc., as applicable.

Wrong assumptions invalidate the entire solution even when the formula is correct. In Electrical Utilization viva and GATE descriptive questions, listing valid assumptions often earns separate marks.

1. Read the question and list given data with SI units (common in Electrical Utilization papers).
2. Draw a neat labelled diagram where applicable — examiners in Indian universities award diagram marks even when arithmetic slips.
3. Identify which relation from this topic applies to illumination engineering.
4. Use equation 1: .
5. Use equation 2: .
6. Substitute values, compute, and verify units and sign (direction).
7. State conclusion in one line — e.g. safe/unsafe, stable/unstable, feasible/infeasible.

Illumination Engineering appears in industry and railways. In Indian electrical curricula this topic is tested because it connects theory to traction, illumination, and heating.

GATE and semester exams often combine illumination engineering with earlier units — revise prerequisites before attempting mixed problems.

Industry interview panels sometimes ask: "Where did you use illumination engineering?" — answer with a lab, mini-project, or plant visit example if possible.

• Omitting the utilisation and maintenance factors in the lumen method
• Forgetting the cosine factor when the surface is not perpendicular to the ray
• Using distance along the surface instead of the slant distance in the inverse-square law
• Confusing luminous intensity (candela) with flux (lumen)

Before attempting illumination engineering problems, confirm you can:

1. Inverse square law: E ∝ I/r² for point source
2.
3. Depreciation factor for lamp lumen maintenance

Revise the solved examples in Art & Science of Utilisation of Electrical Energy — H. Partab and one previous-year GATE or university paper for this unit.
