Wind Energy Conversion System

Wind power scales with the cube of wind speed, P = ½ρAV³, but a turbine can extract at most a fraction C_p (≤ 0.593, the Betz limit) of it — so a small speed increase gives a large power gain.
Exam tip: keep SI units consistent end-to-end, write the governing relation symbolically before substituting, and sanity-check magnitude and sign.

Key formulas & points

Skim these first — then read the full notes below.

  • Cut-in, rated, cut-out wind speeds define operating envelope
  • DFIG and PMSG generator topologies
  • Weibull distribution models wind speed variability

Topic details

Introduction

The cubic dependence on wind speed dominates wind economics: doubling the wind speed gives eight times the power. The swept area A = πR² also matters, so blade length is a key design lever.

Scope in B.Tech and GATE syllabus

The Betz limit caps the power coefficient C_p at 0.593; modern turbines reach 0.4–0.45. The turbine operates between a cut-in speed (below which it will not generate) and a cut-out speed (above which it shuts down to avoid damage), holding rated power in between by pitch control.

Key relations & formulas

Pwind=12ρAV3P_{wind} = \frac{1}{2} \rho A V^{3}
(available wind power)
Pturbine=Cp×PwindP_{turbine} = C_{p} \times P_{wind}
(C_p ≤ 0.593 Betz limit)

Formulas (Indian textbook notation)

  • Tipspeedratioλ=ωRVTip speed ratio \lambda = \omega \frac{R}{V}

Notation and sign conventions

Relation 1 —
Pwind=12ρAV3P_{wind} = \frac{1}{2} \rho A V^{3}
Pwind=12ρAV3P_{wind} = \frac{1}{2} \rho A V^{3}
(available wind power)
Write this relation with symbols exactly as in Non-Conventional Energy Sources — GD Rai before substituting numbers. Examiners award partial marks for a correct setup even when arithmetic slips.
Relation 2 —
Pturbine=Cp×PwindP_{turbine} = C_{p} \times P_{wind}
Pturbine=Cp×PwindP_{turbine} = C_{p} \times P_{wind}
(C_p ≤ 0.593 Betz limit)
Write this relation with symbols exactly as in Non-Conventional Energy Sources — GD Rai before substituting numbers. Examiners award partial marks for a correct setup even when arithmetic slips.
Relation 3 —
Tipspeedratioλ=ωRVTip speed ratio \lambda = \omega \frac{R}{V}

Formulas (Indian textbook notation)

  • Tipspeedratioλ=ωRVTip speed ratio \lambda = \omega \frac{R}{V}
Write this relation with symbols exactly as in Non-Conventional Energy Sources — GD Rai before substituting numbers. Examiners award partial marks for a correct setup even when arithmetic slips.

Fundamentals and definitions

Tip-speed ratio λ = ωR/V is optimised (typically 6–8 for three-blade turbines) to maximise C_p; a variable-speed generator (DFIG or PMSG) keeps λ near optimum as wind speed varies.

Governing relations in practice

Between cut-in and rated speed the controller tracks maximum power; above rated speed, blade pitch is adjusted to spill excess power and hold the generator at its rating.

Design and analysis considerations

Wind resource assessment uses the Weibull distribution to describe the probability of each wind speed, and the annual energy is the integral of the power curve weighted by that distribution.

Assumptions and validity limits

State assumptions explicitly before using any relation for wind energy conversion system — steady state, uniform properties, linear elastic material, ideal gas, incompressible flow, etc., as applicable.
Wrong assumptions invalidate the entire solution even when the formula is correct. In Renewable Energy (EE) viva and GATE descriptive questions, listing valid assumptions often earns separate marks.

Step-by-step problem approach

1. Read the question and list given data with SI units (common in Renewable Energy (EE) papers).
2. Draw a neat labelled diagram where applicable — examiners in Indian universities award diagram marks even when arithmetic slips.
3. Identify which relation from this topic applies to wind energy conversion system.
4. Use equation 1:
Pwind=12ρAV3P_{wind} = \frac{1}{2} \rho A V^{3}
.
5. Use equation 2:
Pturbine=Cp×PwindP_{turbine} = C_{p} \times P_{wind}
.
6. Substitute values, compute, and verify units and sign (direction).
7. State conclusion in one line — e.g. safe/unsafe, stable/unstable, feasible/infeasible.

Applications & exam relevance

Wind Energy Conversion System appears in solar farms and hybrid systems. In Indian electrical curricula this topic is tested because it connects theory to PV, wind, and grid integration.
GATE and semester exams often combine wind energy conversion system with earlier units — revise prerequisites before attempting mixed problems.
Industry interview panels sometimes ask: "Where did you use wind energy conversion system?" — answer with a lab, mini-project, or plant visit example if possible.

Common mistakes in exams

• Using V² instead of V³ in the wind power expression
• Forgetting the swept area is πR² (using diameter as radius)
• Treating C_p as achievable up to 1 (it cannot exceed the Betz 0.593)
• Ignoring air density variation with altitude/temperature

Quick revision checklist

Before attempting wind energy conversion system problems, confirm you can:
1. Cut-in, rated, cut-out wind speeds define operating envelope
2. DFIG and PMSG generator topologies
3. Weibull distribution models wind speed variability
Revise the solved examples in Non-Conventional Energy Sources — GD Rai and one previous-year GATE or university paper for this unit.

Worked examples

Try the problem first — open the solution when you are ready to check.

Power extracted by a wind turbine

Problem

A wind turbine has a rotor diameter of 40 m and operates at a wind speed of 10 m/s with C_p = 0.4. Take air density 1.225 kg/m³. Find the mechanical power extracted.

Solution

Swept area A = πR² = π × 20² = 1256.6 m².
Available wind power = ½ρAV³ = 0.5 × 1.225 × 1256.6 × 10³.
= 0.5 × 1.225 × 1256.6 × 1000 = 769,700 W ≈ 770 kW.
Extracted power = C_p × P_wind = 0.4 × 770 = 308 kW.

Conceptual check — Wind Energy Conversion System

Problem

In a Renewable Energy (EE) semester or GATE paper you are asked: "State the main assumption, the governing relation, and one practical consequence of wind energy conversion system." What should a complete answer include?

Exams & GATE

GD Rai — calculate power at given wind speed and C_p.
