Two Port Networks

Two-port parameters (Z, Y, h, ABCD) describe a linear network entirely by the relations between its input and output voltages and currents, letting you black-box amplifiers, filters and transmission lines for interconnection.

Exam tip: keep SI units consistent end-to-end, write the governing relation symbolically before substituting, and sanity-check magnitude and sign.

Key formulas & points

Skim these first — then read the full notes below.

$Reciprocal network: Z_{12} = Z_{21} or AD - BC = 1 for ABCD$
Cascade connection: multiply ABCD matrices
π and T networks for impedance matching

Topic details

Introduction

Two-port theory is asked because it lets complex sub-circuits be characterised once and reused. Each parameter set is defined by open- or short-circuiting a port: Z-parameters use open-circuit tests (set a current to zero), Y-parameters use short-circuit tests (set a voltage to zero).

Scope in B.Tech and GATE syllabus

The ABCD (transmission) parameters are the workhorse for cascaded systems — power line sections, matching networks — because the overall ABCD matrix is simply the product of the individual matrices in order.

Key relations & formulas

Formulas (Indian textbook notation)

$Z-parameters: V_{1} = Z_{11} I_{1} + Z_{12} I_{2}; V_{2} = Z_{21} I_{1} + Z_{22} I_{2}$

Formulas (Indian textbook notation)

$Y-parameters: I_{1} = Y_{11} V_{1} + Y_{12} V_{2}$

Formulas (Indian textbook notation)

$h-parameters: V_{1} = h_{11} I_{1} + h_{12} V_{2}; I_{2} = h_{21} I_{1} + h_{22} V_{2}$

Formulas (Indian textbook notation)

$ABCD: V_{1} = A V_{2} + B I_{2}; I_{1} = C V_{2} + D I_{2}$

Notation and sign conventions

Relation 1 —

Z-parameters: V_{1} = Z_{11} I_{1} + Z_{12} I_{2}; V_{2} = Z_{21} I_{1} + Z_{22} I_{2}

Formulas (Indian textbook notation)

$Z-parameters: V_{1} = Z_{11} I_{1} + Z_{12} I_{2}; V_{2} = Z_{21} I_{1} + Z_{22} I_{2}$

Write this relation with symbols exactly as in Network Analysis — Nagrath & Kothari before substituting numbers. Examiners award partial marks for a correct setup even when arithmetic slips.

Relation 2 —

Y-parameters: I_{1} = Y_{11} V_{1} + Y_{12} V_{2}

Formulas (Indian textbook notation)

$Y-parameters: I_{1} = Y_{11} V_{1} + Y_{12} V_{2}$

Write this relation with symbols exactly as in Network Analysis — Nagrath & Kothari before substituting numbers. Examiners award partial marks for a correct setup even when arithmetic slips.

Relation 3 —

h-parameters: V_{1} = h_{11} I_{1} + h_{12} V_{2}; I_{2} = h_{21} I_{1} + h_{22} V_{2}

Formulas (Indian textbook notation)

$h-parameters: V_{1} = h_{11} I_{1} + h_{12} V_{2}; I_{2} = h_{21} I_{1} + h_{22} V_{2}$

Write this relation with symbols exactly as in Network Analysis — Nagrath & Kothari before substituting numbers. Examiners award partial marks for a correct setup even when arithmetic slips.

Relation 4 —

ABCD: V_{1} = A V_{2} + B I_{2}; I_{1} = C V_{2} + D I_{2}

Formulas (Indian textbook notation)

$ABCD: V_{1} = A V_{2} + B I_{2}; I_{1} = C V_{2} + D I_{2}$

Write this relation with symbols exactly as in Network Analysis — Nagrath & Kothari before substituting numbers. Examiners award partial marks for a correct setup even when arithmetic slips.

Fundamentals and definitions

To find Z₁₁, open-circuit port 2 (I₂ = 0) and compute V₁/I₁. To find Z₁₂, drive port 2 and measure V₁/I₂ with port 1 open. The h-parameters mix a short-circuit input test (h₁₁, h₂₁ with V₂ = 0) and an open-circuit output test (h₁₂, h₂₂ with I₁ = 0), which is why they suit BJT modelling.

Governing relations in practice

Reciprocity (Z₁₂ = Z₂₁, or AD − BC = 1) holds for networks with no dependent sources. Symmetry (Z₁₁ = Z₂₂, or A = D) adds the condition that the two ports are electrically interchangeable.

Design and analysis considerations

Convert between parameter sets using standard determinant relations rather than re-deriving from scratch under exam time pressure.

Assumptions and validity limits

State assumptions explicitly before using any relation for two port networks — steady state, uniform properties, linear elastic material, ideal gas, incompressible flow, etc., as applicable.

Wrong assumptions invalidate the entire solution even when the formula is correct. In Network Analysis viva and GATE descriptive questions, listing valid assumptions often earns separate marks.

Step-by-step problem approach

1. Read the question and list given data with SI units (common in Network Analysis papers).
2. Draw a neat labelled diagram where applicable — examiners in Indian universities award diagram marks even when arithmetic slips.
3. Identify which relation from this topic applies to two port networks.
4. Use equation 1:

Z-parameters: V_{1} = Z_{11} I_{1} + Z_{12} I_{2}; V_{2} = Z_{21} I_{1} + Z_{22} I_{2}

.
5. Use equation 2:

Y-parameters: I_{1} = Y_{11} V_{1} + Y_{12} V_{2}

.
6. Substitute values, compute, and verify units and sign (direction).
7. State conclusion in one line — e.g. safe/unsafe, stable/unstable, feasible/infeasible.

Applications & exam relevance

Two Port Networks appears in all electrical engineering circuits. In Indian electrical curricula this topic is tested because it connects theory to DC/AC circuit analysis.

GATE and semester exams often combine two port networks with earlier units — revise prerequisites before attempting mixed problems.

Industry interview panels sometimes ask: "Where did you use two port networks?" — answer with a lab, mini-project, or plant visit example if possible.

Common mistakes in exams

• Confusing the reference direction of I₂ (into the network) between conventions, especially for ABCD
• Applying an open-circuit test where a short-circuit test is required (Z vs Y)
• Multiplying ABCD matrices in the wrong cascade order
• Assuming reciprocity when a dependent source is present

Quick revision checklist

Before attempting two port networks problems, confirm you can:

1.

Reciprocal network: Z_{12} = Z_{21} or AD - BC = 1 for ABCD

2. Cascade connection: multiply ABCD matrices
3. π and T networks for impedance matching

Revise the solved examples in Network Analysis — Nagrath & Kothari and one previous-year GATE or university paper for this unit.

Worked examples

Try the problem first — open the solution when you are ready to check.

Z-parameters of a T-network

Problem

A symmetric T-network has series arms of 10 Ω each and a shunt arm of 20 Ω at the centre. Find its Z-parameters.

Solution

Z₁₁ = V₁/I₁ with I₂ = 0 (port 2 open): input sees 10 Ω series + 20 Ω shunt = 30 Ω. Z₁₁ = 30 Ω.
By symmetry Z₂₂ = 30 Ω.
Z₁₂ = V₁/I₂ with I₁ = 0: with port 1 open, I₂ flows into the shunt 20 Ω; V₁ appears across it. Z₁₂ = 20 Ω.
Reciprocity gives Z₂₁ = Z₁₂ = 20 Ω.
So [Z] = [[30, 20],[20, 30]] Ω.

Conceptual check — Two Port Networks

Problem

In a Network Analysis semester or GATE paper you are asked: "State the main assumption, the governing relation, and one practical consequence of two port networks." What should a complete answer include?

Exams & GATE

Nagrath & Kothari — convert between parameter sets for given network.
