Phases in Fe-C Diagram

The Fe-C diagram's phases are ferrite (α, soft BCC), austenite (γ, FCC), cementite (Fe₃C, hard), and their mixtures pearlite and ledeburite. Key lines are A₁ = 727 °C (eutectoid) and A₃ (varies with %C), per physical-metallurgy texts.
Exam tip: keep SI units consistent end-to-end, write the governing relation symbolically before substituting, and sanity-check magnitude and sign.

Key formulas & points

Skim these first — then read the full notes below.

  • Cementite (Fe₃C) metastable — graphite in cast iron
  • Ledeburite: eutectic mixture austenite + cementite
  • Proeutectoid ferrite or cementite forms above/below eutectoid

Topic details

Introduction

Identifying the phases and constituents of the iron-carbon diagram is the starting point of ferrous heat treatment. This entry focuses specifically on naming and characterising each phase and microconstituent.

Scope in B.Tech and GATE syllabus

Ferrite is nearly pure iron (soft, ductile); austenite exists only above A₁ (high carbon solubility); cementite is the hard 6.67 % C carbide. Pearlite (alternating ferrite + cementite lamellae) forms from austenite at the eutectoid, and ledeburite from the eutectic in cast irons.

Why this topic matters in practice

Distinguishing a phase (a distinct structure/composition) from a microconstituent (a characteristic mixture like pearlite) is a common conceptual question. Locating each on the diagram and stating its properties are the exam skills.

Key relations & formulas

A1=727§K0§C(eutectoid);A3=hypohypoboundaryA_{1} = 727^{§K0§}C (eutectoid); A_{3} = hypo hypo boundary
(varies with %C)
Acm=1147§K0§C(eutectic);A4=1538§K1§CA_{cm} = 1147^{§K0§}C (eutectic); A_{4} = 1538^{§K1§}C
(peritectic region)

Formulas (Indian textbook notation)

  • MaxCinaustenite:2.11Max C in austenite: 2.11% at 1147^{§K0§}C

Formulas (Indian textbook notation)

  • MaxCinferrite:0.022Max C in ferrite: 0.022% at 727^{§K0§}C

Notation and sign conventions

Relation 1 —
A1=727§K0§CA_{1} = 727^{§K0§}C
A1=727§K0§C(eutectoid);A3=hypohypoboundaryA_{1} = 727^{§K0§}C (eutectoid); A_{3} = hypo hypo boundary
(varies with %C)
Write this relation with symbols exactly as in Metallurgical Thermodynamics — Dekkar before substituting numbers. Examiners award partial marks for a correct setup even when arithmetic slips.
Relation 2 —
Acm=1147§K0§CA_{cm} = 1147^{§K0§}C
Acm=1147§K0§C(eutectic);A4=1538§K1§CA_{cm} = 1147^{§K0§}C (eutectic); A_{4} = 1538^{§K1§}C
(peritectic region)
Write this relation with symbols exactly as in Metallurgical Thermodynamics — Dekkar before substituting numbers. Examiners award partial marks for a correct setup even when arithmetic slips.
Relation 3 —
MaxCinaustenite:2.11Max C in austenite: 2.11% at 1147^{§K0§}C

Formulas (Indian textbook notation)

  • MaxCinaustenite:2.11Max C in austenite: 2.11% at 1147^{§K0§}C
Write this relation with symbols exactly as in Metallurgical Thermodynamics — Dekkar before substituting numbers. Examiners award partial marks for a correct setup even when arithmetic slips.
Relation 4 —
MaxCinferrite:0.022Max C in ferrite: 0.022% at 727^{§K0§}C

Formulas (Indian textbook notation)

  • MaxCinferrite:0.022Max C in ferrite: 0.022% at 727^{§K0§}C
Write this relation with symbols exactly as in Metallurgical Thermodynamics — Dekkar before substituting numbers. Examiners award partial marks for a correct setup even when arithmetic slips.

Fundamentals and definitions

Ferrite (α) is BCC iron with very little carbon (max 0.022 % at 727 °C) — soft, ductile, and magnetic. Austenite (γ) is FCC iron dissolving up to 2.14 % C at 1147 °C — non-magnetic and only stable at high temperature in plain steels.

Governing relations in practice

Cementite (Fe₃C) is a hard, brittle intermetallic of fixed 6.67 % C; it provides strength when finely distributed. δ-ferrite is a high-temperature BCC phase near melting.

Design and analysis considerations

Microconstituents are characteristic phase mixtures: pearlite is the lamellar ferrite + cementite eutectoid product (0.76 % C) formed on cooling austenite through 727 °C; ledeburite is the austenite + cementite eutectic (4.3 % C) in cast irons.

Advanced theory and extensions

The A₁ line at 727 °C is the eutectoid temperature (austenite → pearlite); A₃ is the ferrite/austenite boundary that falls with carbon from 912 °C to 727 °C; A_cm is the cementite solubility line. Knowing each phase, constituent, and line is the foundation for reading microstructures.

Assumptions and validity limits

State assumptions explicitly before using any relation for phases in fe-c diagram — steady state, uniform properties, linear elastic material, ideal gas, incompressible flow, etc., as applicable.
Wrong assumptions invalidate the entire solution even when the formula is correct. In Iron–Carbon Diagram viva and GATE descriptive questions, listing valid assumptions often earns separate marks.

Step-by-step problem approach

1. Read the question and list given data with SI units (common in Iron–Carbon Diagram papers).
2. Draw a neat labelled diagram where applicable — examiners in Indian universities award diagram marks even when arithmetic slips.
3. Identify which relation from this topic applies to phases in fe-c diagram.
4. Use equation 1:
A1=727§K0§CA_{1} = 727^{§K0§}C
.
5. Use equation 2:
Acm=1147§K0§CA_{cm} = 1147^{§K0§}C
.
6. Substitute values, compute, and verify units and sign (direction).
7. State conclusion in one line — e.g. safe/unsafe, stable/unstable, feasible/infeasible.

Applications & exam relevance

Phases in Fe-C Diagram appears in heat treatment shop decisions. In Indian mechanical curricula this topic is tested because it connects theory to phases and transformations in steels.
GATE and semester exams often combine phases in fe-c diagram with earlier units — revise prerequisites before attempting mixed problems.
Industry interview panels sometimes ask: "Where did you use phases in fe-c diagram?" — answer with a lab, mini-project, or plant visit example if possible.

Common mistakes in exams

• Confusing a phase (ferrite, austenite, cementite) with a microconstituent (pearlite, ledeburite)
• Placing the eutectoid temperature anywhere other than 727 °C
• Forgetting austenite is unstable at room temperature in plain carbon steel
• Mixing up A₃ (ferrite boundary) and A_cm (cementite boundary)

Quick revision checklist

Before attempting phases in fe-c diagram problems, confirm you can:
1. Cementite (Fe₃C) metastable — graphite in cast iron
2. Ledeburite: eutectic mixture austenite + cementite
3. Proeutectoid ferrite or cementite forms above/below eutectoid
Revise the solved examples in Metallurgical Thermodynamics — Dekkar and one previous-year GATE or university paper for this unit.

Worked examples

Try the problem first — open the solution when you are ready to check.

Phase identification

Problem

Name the microconstituent formed when austenite of 0.76 % C is cooled slowly through 727 °C, and state its structure.

Solution

It forms pearlite — a lamellar mixture of soft ferrite and hard cementite produced by the eutectoid reaction at 727 °C.

Conceptual check — Phases in Fe-C Diagram

Problem

In a Iron–Carbon Diagram semester or GATE paper you are asked: "State the main assumption, the governing relation, and one practical consequence of phases in fe-c diagram." What should a complete answer include?

Practice questions

Most-asked interview and GATE questions for this topic — expand any item for a model answer.

  1. 1
    What is Phases in Fe-C Diagram, and why does it appear in B.Tech / GATE syllabi?

    Model answer

    The Fe-C diagram's phases are ferrite (α, soft BCC), austenite (γ, FCC), cementite (Fe₃C, hard), and their mixtures pearlite and ledeburite. Key lines are A₁ = 727 °C (eutectoid) and A₃ (varies with %C), per physical-metallurgy texts.
  2. 2
    State the relation A₁ = 727°C and name each symbol.

    Model answer

    The governing relation is A1=727§K0§CA_{1} = 727^{§K0§}C. Write every symbol with SI units before substituting numbers.
  3. 3
    State the relation A_cm = 1147°C and name each symbol.

    Model answer

    The governing relation is Acm=1147§K0§CA_{cm} = 1147^{§K0§}C. Write every symbol with SI units before substituting numbers.
  4. 4
    State the relation Max C in austenite: 2.11% at 1147°C and name each symbol.

    Model answer

    The governing relation is MaxCinaustenite:2.11Max C in austenite: 2.11% at 1147^{§K0§}C. Write every symbol with SI units before substituting numbers.
  5. 5
    State the relation Max C in ferrite: 0.022% at 727°C and name each symbol.

    Model answer

    The governing relation is MaxCinferrite:0.022Max C in ferrite: 0.022% at 727^{§K0§}C. Write every symbol with SI units before substituting numbers.
  6. 6
    Explain: Cementite (Fe₃C) metastable — graphite in cast iron

    Model answer

    Cementite (Fe₃C) metastable — graphite in cast iron — state the assumption range and one exam trap linked to this point.
  7. 7
    Explain: Ledeburite: eutectic mixture austenite + cementite

    Model answer

    Ledeburite: eutectic mixture austenite + cementite — state the assumption range and one exam trap linked to this point.
  8. 8
    Explain: Proeutectoid ferrite or cementite forms above/below eutectoid

    Model answer

    Proeutectoid ferrite or cementite forms above/below eutectoid — state the assumption range and one exam trap linked to this point.
  9. 9
    How would you correct this error in a viva: Confusing a phase (ferrite, austenite, cementite) with a microconstituent (pearlite, ledeburite)?

    Model answer

    Identify the wrong assumption or unit mix-up, rewrite the correct relation, and recompute with a one-line sanity check.
  10. 10
    How would you correct this error in a viva: Placing the eutectoid temperature anywhere other than 727 °C?

    Model answer

    Identify the wrong assumption or unit mix-up, rewrite the correct relation, and recompute with a one-line sanity check.
  11. 11
    How would you correct this error in a viva: Forgetting austenite is unstable at room temperature in plain carbon steel?

    Model answer

    Identify the wrong assumption or unit mix-up, rewrite the correct relation, and recompute with a one-line sanity check.
  12. 12
    How would you correct this error in a viva: Mixing up A₃ (ferrite boundary) and A_cm (cementite boundary)?

    Model answer

    Identify the wrong assumption or unit mix-up, rewrite the correct relation, and recompute with a one-line sanity check.

Exams & GATE

  • 1
    Dekkar — draw and label complete Fe-Fe₃C diagram with invariant points.
  • 2
    Avoid: Confusing a phase (ferrite, austenite, cementite) with a microconstituent (pearlite, ledeburite)
  • 3
    Avoid: Placing the eutectoid temperature anywhere other than 727 °C
  • 4
    Avoid: Forgetting austenite is unstable at room temperature in plain carbon steel

📖 Standard books (India)

  • Metallurgical Thermodynamics — Dekkar

    Read: Syllabus unit

    Iron-carbon, heat treatment, and alloys
